FEATURES

• Size 31 Housing, NEMA4/IP66 Heavy-duty Enclosure.
• Std. Electrically, Thermally Insulated & Isolated Hub.
• Std. Equipped with 56C Cover & Tether Mtg. Bracket.
• Hub I.D. 5/8", 3/4", 7/8", 1", Thru-hub deisgn.
• Up to 1024 ppr and Unbreakable Code Disk.
• Electrical Protection Std.: Voltage Transients, Reverse Voltage, Output Short Circuit Proof.
• Super Linedriver 5-26v, Push-Pull 5-26v TTL outputs.
  Linedriver or TTL (RS422 compatible) Complimentary-6ch.
  input 8-30v, output 5v
  Industrial Encoder IH950 Interchangeable.
• Military Std. 7 pin, 10 pin, Conn. NEMA4/IP66
• D-sub 9 pin, 10ft. Cable w/Straight Plug. NEMA12/IP50
